Type | 4 OCSH 40 | 5 OCSH 40 | 6 OCSH 40 | 8 OCSH 40 | 10 OCSH 45 | ø d | M4 | M5 | M6 | M8 | M10 | l [+0,5/-0] | 12,5 | 13,5 | 15,5 | 18,5 | 21,0 | Grip range | 1,5-4,0 | 1,5-4,0 | 1,5-4,0 | 1,5-4,0 | 2,0-4,5 | Drill ø | 6,0 | 7,0 | 9,0 | 11,0 | 13,0 | ø dk | 8,5 | 9,5 | 11,5 | 13,5 | 15,5 | k | ≤ 1,5 | ≤ 1,5 | ≤ 1,5 | ≤ 1,5 | ≤ 1,8 | ø d [+0/-0,2] | 5,9 | 6,9 | 8,9 | 10,9 | 12,9 |
|
